Description
Overview
The Graco K45FH1 is a high-performance, heavy-duty airless sprayer designed for industrial applications such as shipbuilding, bridge maintenance, and protective coatings. Built with the XL6500 air motor and a 45:1 pressure ratio, this sprayer delivers consistent results even in the toughest environments.
Key Features
- 45:1 pressure ratio with XL6500 air motor
- Max fluid pressure: 4,500 psi (310 bar)
- Heavy-duty cart with integrated air controls and filter
- Includes: Siphon feed kit, XTR-5+ spray gun, 50 ft hose, 6 ft whip
- De-icing valve: Reduces cold weather icing issues
- Multi-gun support: Minimal pulsation, consistent spray pattern
Technical Specifications
| Specification | Details |
|---|---|
| Model | K45FH1 |
| Ratio | 45:1 |
| Max Fluid Pressure | 4,500 psi (310 bar) |
| Max Air Inlet Pressure | 100 psi |
| Air Inlet | 1″ NPT (F) |
| Fluid Inlet | 1¼″ NPT (M) |
| Fluid Outlet | ½″ NPT (F) |
| Stroke Length | 4.75″ |
| Motor | XL6500 Pneumatic Air Motor |
| Sound Level | 81.5 dB(A) |
| Weight | 215 lb (98 kg) |
| Wetted Materials | Stainless Steel, Nickel, Tungsten Carbide, PTFE, Leather |
| Certifications | FM, CE, Ex-rated (Hazardous Locations) |
What’s Included
- Graco K45FH1 Pump Unit (on Cart)
- Integrated Air Controls and Filter
- Siphon Feed Kit
- XTR-5+ Spray Gun
- 50 ft Hose + 6 ft Whip Hose
- User Manual and Maintenance Guide
